Industrial Generator • BAUDOUN

KT-C Serial Powered by BAUDOUN

Prime & standby diesel sets engineered for reliability, supported across KSA & the region.

LG-C Serial Powered by CUMMINS

KT-P Serial Powered by BAUDOUN

GENSET
MODEL 		ESP PRP ENGINE TYPE ALTERNATOR DIMENSION DATASHEET
KW KVA KW KVA KT POWER Leroy
Sommer		 OPEN TYPE SILENT TYPE
KT15BD 16.5 20.625 15 18.75 4M06G20/6 LK184E LSA 40 M7 OP1500*750*1050 AT2188*900*1280
KT18BD 19.8 24.75 18 22.5 4M06G25/6 LK184E LSA 40 M7 OP1500*750*1050 AT2188*900*1280
KT25BD 28.6 35.75 26 32.5 4M06G33/6 LK184G LSA 42.3 VS3 OP1500*750*1050 AT2188*900*1280
KT32BD 35.2 44 32 40 4M06G41/6 LK184H LSA 42.3 S5 OP1500*750*1050 AT2188*900*1280
KT36BD 39.6 49.5 36 45 4M06G50/6 LK224D LSA 42.3 M8 OP1850*800*1100 AT2288*950*1280
KT40BD 44 55 40 50 4M06G55/6 LK224D LSA 42.3 M8 OP1850*800*1100 AT2288*950*1280
KT64BD 70.4 88 64 80 4M10G83/6 LK224F LSA 44.3 S2 OP1900*870*1180 AT2688*1080*1450
KT80BD 88 110 80 100 4M10G100/6 LK274C LSA 44.3 S5 OP2050*880*1230 AT2938*1080*1690
KT110BD 118.8 148.5 108 135 6M11G135/6 LK274D LSA 44.3 M6 OP2400*950*1510 AT3288*1130*1850
KT120BD 132 165 120 150 6M11G160/6 LK274F/S LSA 44.3 L10 OP2400*950*1510 AT3288*1130*1850
KT160BD 176 220 160 200 6M16G200/6 LK274H LSA 44.3 VL14 OP2850*1040*1580 AT3958*1280*2150
KT184BD 202.4 253 184 230 6M16G220/6 LK274J LSA46.3 S4 OP2850*1040*1580 AT3958*1280*2150
KT200BD 220 275 200 250 6M16G250/6 LK274K LSA46.3 S5 OP2850*1050*1620 AT3958*1280*2150
KT260BD 281.6 352 256 320 6M16G308/6 LK444E LSA46.3 L11 OP3050*1100*1800 AT4188*1400*2220
KT280BD 308 385 280 350 6M21G330/6 LK444FS LSA46.3 L11 OP3350*1150*1800 AT4188*1400*2220
KT320BD 352 440 320 400 6M21G390/6 LK444F LSA 47.3 S4 OP3350*1150*1800 AT4588*1600*2500
KT360BD 396 495 360 450 6M21G400/6 LK544C LSA 47.3 M7 OP3350*1150*1800 AT4588*1600*2500
KT400BD 440 550 400 500 6M21G460/6 LK544D LSA 47.3 M8 OP3350*1150*1800 AT4588*1600*2500
KT480BD 528 660 480 600 6M33G575/6 LK544E LSA 47.3 L9 OP3800*1600*2200 AT5280*2100*2500
KT520BD 572 715 520 650 6M33G600/6 LK544F LSA49.3 S4 OP3800*1600*2200 AT5280*2100*2500
KT550BD 598.4 748 544 680 6M33G633/6 LK544F LSA49.3 S4 OP3800*1600*2200 AT5680*2100*2500
KT600BD 660 825 600 750 6M33G660/6 LK634B LSA49.3 M65 OP3800*1600*2200 AT5680*2100*2500
KT650BD 717.2 896.5 652 815 12M26G800/6 LK634C LSA49.3 M8 OP4100*2000*2250 20FT
KT720BD 792 990 720 900 12M26G900/6 LK634D LSA49.3 L9 OP4100*2000*2250 20FT
KT820BD 897.6 1122 816 1020 12M26G1000/6 LK634E LSA49.3 L10 OP4400*2000*2250 20FT
KT920BD 1012 1265 920 1150 12M33G1000/6 LK634F LSA 50.2 M6 OP4700*2200*2400 40HQ
KT1000BD 1100 1375 1000 1250 12M33G1100/6 LK634G LSA 50.2 M6 OP4700*2200*2400 40HQ
KT1100BD 1210 1512.5 1100 1375 12M33G1300/6 LK734B LSA 50.2 L8 OP4700*2200*2400 40HQ
KT1200BD 1320 1650 1200 1500 12M33G1320/6 LK734B LSA 50.2 L8 OP4700*2200*2400 40HQ
KT1200BD 1320 1650 1200 1500 16M33G1500/6 LK734C LSA 50.2 L8 OP5400*2250*2500 40HQ
KT1400BD 1540 1925 1400 1750 16M33G1650/6 LK734E LSA52.3 S5 OP5400*2250*2500 40HQ
KT1500BD 1650 2062.5 1500 1875 16M33G1750/6 LK734E LSA52.3 S5 OP5400*2250*2500 40HQ
KT1600WP 1760 2200 1600 2000 20M33G2000/6 LK734F LSA52.3 S6 OP5400*2250*2500 40HQ*
KT1800WP 1980 2475 1800 2250 20M33G2200/6 LK734G LSA52.3 S7 OP5800*2800*3400 40HQ*
KT1800WP 1980 2475 1800 2250 12M55G2250/6 LK734G LSA52.3 S7 OP5800*2800*3400 40HQ*
KT2000WP 2200 2750 2000 2500 12M55G2500/6 LK734H LSA52.3 L12 OP6200*2850*3290 40HQ*
KT2200WP 2420 3025 2200 2750 16M55G2640/6 LK734HM LSA52.3 UL16 C6S/4 OP6500*2850*3290 40HQ*
KT2200WP 2420 3025 2200 2750 16M55G2800/6 LK734HM LSA52.3 UL16 C6S/4 OP6500*2850*3290 40HQ*
KT2400WP 2640 3300 2400 3000 16M55G3000/6 LK734HG LSA53.2M9 OP6500*2850*3290 40HQ*
KT2600WP 2860 3575 2600 3250 16M55G3300/6 无 LSA54.2M10 2736KW OP6500*2850*3290 40HQ*
